58 01-6203-01R3, CG Drives & Automation
Display code
Short designation
Default setting
Setting range
Address
Category
└ P531.03
Register 3
-
(Read only)
0x232C:003
Modbus RTU
└ P531.04 Register 4 - (Read only) 0x232C:004 Modbus RTU
└ P531.05
Register 5
-
(Read only)
0x232C:005
Modbus RTU
└ P531.06
Register 6
-
(Read only)
0x232C:006
Modbus RTU
└ P531.07
Register 7
-
(Read only)
0x232C:007
Modbus RTU
└ P531.08
Register 8
-
(Read only)
0x232C:008
Modbus RTU
└ P531.09 Register 9 - (Read only) 0x232C:009 Modbus RTU
└ P531.10
Register 10
-
(Read only)
0x232C:010
Modbus RTU
└ P531.11
Register 11
-
(Read only)
0x232C:011
Modbus RTU
└ P531.12
Register 12
-
(Read only)
0x232C:012
Modbus RTU
└ P531.13
Register 13
-
(Read only)
0x232C:013
Modbus RTU
└ P531.14 Register 14 - (Read only) 0x232C:014 Modbus RTU
└ P531.15
Register 15
-
(Read only)
0x232C:015
Modbus RTU
└ P531.16
Register 16
-
(Read only)
0x232C:016
Modbus RTU
└ P531.17
Register 17
-
(Read only)
0x232C:017
Modbus RTU
└ P531.18
Register 18
-
(Read only)
0x232C:018
Modbus RTU
└ P531.19 Register 19 - (Read only) 0x232C:019 Modbus RTU
└ P531.20
Register 20
-
(Read only)
0x232C:020
Modbus RTU
└ P531.21
Register 21
-
(Read only)
0x232C:021
Modbus RTU
└ P531.22
Register 22
-
(Read only)
0x232C:022
Modbus RTU
└ P531.23
Register 23
-
(Read only)
0x232C:023
Modbus RTU
└ P531.24 Register 24 - (Read only) 0x232C:024 Modbus RTU
P532.00
Verificationcode
-
(Read only)
0x232D
Modbus RTU
P540.xx
RPDO1 config.
└ P540.01
COB-ID
0x00000200
0x00000000 ... 0xFFFFFFFF
0x1400:001
CANopen
└ P540.02
Transm. type
255
0 ... 255
0x1400:002
CANopen
└ P540.05 Event timer 100 ms 0 ... 65535 ms 0x1400:005 CANopen
P541.xx
RPDO2 config.
└ P541.01
COB-ID
0x80000300
0x00000000 ... 0xFFFFFFFF
0x1401:001
CANopen
└ P541.02
Transm. type
255
0 ... 255
0x1401:002
CANopen
└ P541.05
Event timer
100 ms
0 ... 65535 ms
0x1401:005
CANopen
P542.xx RPDO3 config.
└ P542.01
COB-ID
0x80000400
0x00000000 ... 0xFFFFFFFF
0x1402:001
CANopen
└ P542.02
Transm. type
255
0 ... 255
0x1402:002
CANopen
└ P542.05
Event timer
100 ms
0 ... 65535 ms
0x1402:005
CANopen
P550.xx
TPDO1 config.
└ P550.01 COB-ID 0x40000180 0x00000001 ... 0xFFFFFFFF 0x1800:001 CANopen
└ P550.02
Transm. type
255
0 ... 255
0x1800:002
CANopen
└ P550.03
Inhibit time
0.0 ms
0.0 ... 6553.5 ms
0x1800:003
CANopen
└ P550.05
Event timer
20 ms
0 ... 65535 ms
0x1800:005
CANopen
P551.xx
TPDO2 config.
└ P551.01 COB-ID 0xC0000280 0x00000001 ... 0xFFFFFFFF 0x1801:001 CANopen
└ P551.02
Transm. type
255
0 ... 255
0x1801:002
CANopen
└ P551.03
Inhibit time
0.0 ms
0.0 ... 6553.5 ms
0x1801:003
CANopen
└ P551.05
Event timer
0 ms
0 ... 65535 ms
0x1801:005
CANopen
P552.xx
TPDO3 config.
└ P552.01 COB-ID 0xC0000380 0x00000001 ... 0xFFFFFFFF 0x1802:001 CANopen
└ P552.02
Transm. type
255
0 ... 255
0x1802:002
CANopen
