Emotron VS10 - Page 59

Display code
Short designation
Default setting
Setting range
Address
Category
└ P552.03
Inhibit time
0.0 ms
0.0 ... 6553.5 ms
0x1802:003
CANopen
└ P552.05 Event timer 0 ms 0 ... 65535 ms 0x1802:005 CANopen
P580.xx
CAN statistics
└ P580.01
PDO1 received
-
(Read only)
0x230A:001
CANopen
└ P580.02
PDO2 received
-
(Read only)
0x230A:002
CANopen
└ P580.03
PDO3 received
-
(Read only)
0x230A:003
CANopen
└ P580.05 PDO1 transmitted - (Read only) 0x230A:005 CANopen
└ P580.06
PDO2 transmitted
-
(Read only)
0x230A:006
CANopen
└ P580.07
PDO3 transmitted
-
(Read only)
0x230A:007
CANopen
└ P580.09
SDO1 counter
-
(Read only)
0x230A:009
CANopen
└ P580.10
SDO2 counter
-
(Read only)
0x230A:010
CANopen
P580.xx Modbus statistic
└ P580.01
Mess. received
-
(Read only)
0x232A:001
Modbus RTU
└ P580.02
Val. mess. rec.
-
(Read only)
0x232A:002
Modbus RTU
└ P580.03
Mess. w. exc.
-
(Read only)
0x232A:003
Modbus RTU
└ P580.04
Mess. w. errors
-
(Read only)
0x232A:004
Modbus RTU
└ P580.05 Messages sent - (Read only) 0x232A:005 Modbus RTU
P583.xx
Rx data diagn.
└ P583.01
Rx data offset
0
0 ... 240
0x232E:001
Modbus RTU
└ P583.02
Last RxD byte0
-
(Read only)
0x232E:002
Modbus RTU
└ P583.03
Last RxD byte1
-
(Read only)
0x232E:003
Modbus RTU
└ P583.04 Last RxD byte2 - (Read only) 0x232E:004 Modbus RTU
└ P583.05
Last RxD byte3
-
(Read only)
0x232E:005
Modbus RTU
└ P583.06
Last RxD byte4
-
(Read only)
0x232E:006
Modbus RTU
└ P583.07
Letzt RxD-Byte5
-
(Read only)
0x232E:007
Modbus RTU
└ P583.08
Last RxD byte6
-
(Read only)
0x232E:008
Modbus RTU
└ P583.09 Last RxD byte7 - (Read only) 0x232E:009 Modbus RTU
└ P583.10
Last RxD byte8
-
(Read only)
0x232E:010
Modbus RTU
└ P583.11
Last RxD byte9
-
(Read only)
0x232E:011
Modbus RTU
└ P583.12
Last RxD byte10
-
(Read only)
0x232E:012
Modbus RTU
└ P583.13
Last RxD byte11
-
(Read only)
0x232E:013
Modbus RTU
└ P583.14 Last RxD byte12 - (Read only) 0x232E:014 Modbus RTU
└ P583.15
Last RxD byte13
-
(Read only)
0x232E:015
Modbus RTU
└ P583.16
Last RxD byte14
-
(Read only)
0x232E:016
Modbus RTU
└ P583.17
Last RxD byte15
-
(Read only)
0x232E:017
Modbus RTU
P585.xx
Tx data diagn.
└ P585.01 Tx data offset 0 0 ... 240 0x232F:001 Modbus RTU
└ P585.02
Last TxD byte0
-
(Read only)
0x232F:002
Modbus RTU
└ P585.03
Last TxD Byte1
-
(Read only)
0x232F:003
Modbus RTU
└ P585.04
Last TxD byte2
-
(Read only)
0x232F:004
Modbus RTU
└ P585.05
Last TxD byte3
-
(Read only)
0x232F:005
Modbus RTU
└ P585.06 Last TxD byte4 - (Read only) 0x232F:006 Modbus RTU
└ P585.07
Last TxD byte5
-
(Read only)
0x232F:007
Modbus RTU
└ P585.08
Last TxD byte6
-
(Read only)
0x232F:008
Modbus RTU
└ P585.09
Last TxD byte7
-
(Read only)
0x232F:009
Modbus RTU
└ P585.10
Last TxD byte8
-
(Read only)
0x232F:010
Modbus RTU
└ P585.11 Last TxD byte9 - (Read only) 0x232F:011 Modbus RTU
└ P585.12
Last TxD byte10
-
(Read only)
0x232F:012
Modbus RTU
