Display code
Short designation
Default setting
Setting range
Address
Category
└ P585.13
Last TxD byte11
-
(Read only)
0x232F:013
Modbus RTU
└ P585.14 Last TxD byte12 - (Read only)
0x232F:014
Modbus RTU
└ P585.15
Last TxD byte13
-
(Read only)
0x232F:015
Modbus RTU
└ P585.16
Last TxD byte14
-
(Read only)
0x232F:016
Modbus RTU
└ P585.17
Last TxD byte15
-
(Read only)
0x232F:017
Modbus RTU
P590.xx
NetWordINx
└ P590.01 NetWordIN1 0x0000 0x0000 ... 0xFFFF 0x4008:001 general
└ P590.02
NetWordIN2
0x0000
0x0000 ... 0xFFFF
0x4008:002
general
└ P590.03
NetWordIN3
0.0 %
0.0 ... 100.0 %
0x4008:003
general
└ P590.04
NetWordIN4
0.0 %
0.0 ... 100.0 %
0x4008:004
general
P591.xx
NetWordOUTx
└ P591.01 NetWordOUT1 - (Read only) 0x400A:001 general
└ P591.02
NetWordOUT2
-
(Read only)
0x400A:002
general
P592.xx
Process data IN
└ P592.01
AC control word
0x0000
0x0000 ... 0xFFFF
0x400B:001
general
└ P592.02
LECOM ctrl word
0x0000
0x0000 ... 0xFFFF
0x400B:002
general
└ P592.03 Net.freq. 0.1 0.0 Hz 0.0 ... 599.0 Hz 0x400B:003 general
└ P592.04
Net.setp. speed
0 rpm
0 ... 50000 rpm
0x400B:004
general
└ P592.05
Net.freq. 0.01
0.00 Hz
0.00 ... 599.00 Hz
0x400B:005
general
└ P592.06
Veloc. mode setp
0.0 Hz
-599.0 ... 599.0 Hz
0x400B:006
general
└ P592.07
PID setpoint
0.00 PID unit
-300.00 ... 300.00 PID unit
0x400B:007
general
└ P592.08 Torque mode setp 0 Nm -32768 ... 32767 Nm 0x400B:008 general
└ P592.09
Torque scaling
0
-128 ... 127
0x400B:009
general
└ P592.11
PID feedback
0.00 PID unit
-300.00 ... 300.00 PID unit
0x400B:011
general
└ P592.12
NetSetfreq0.02Hz
0 Hz
-29950 ... 29950 Hz
0x400B:012
general
P593.xx
Process data OUT
└ P593.01 AC status word - (Read only) 0x400C:001 general
└ P593.02
LECOM stat. word
-
(Read only)
0x400C:002
general
└ P593.03
Frequency (0.1)
x.x Hz
(Read only)
0x400C:003
general
└ P593.04
Motor speed
x rpm
(Read only)
0x400C:004
general
└ P593.05
Drive status
-
(Read only)
0x400C:005
general
└ P593.06 Frequency 0.01 x.xx Hz (Read only) 0x400C:006 general
└ P593.07
Torque scaled
-
(Read only)
0x400C:007
general
└ P593.08
Frequency 0.02Hz
Hz
(Read only)
0x400C:008
general
P595.xx
PAM monitoring
└ P595.02
Keep alive reg.
0
0 ... 65535
0x2552:002
general
└ P595.03 Time-out time 10.0 s 0.0 ... 6553.5 s 0x2552:003 general
└ P595.04
Reaction
No response [0]
Selection list
0x2552:004
general
└ P595.05
Action
No action [0]
Selection list
0x2552:005
general
└ P595.06
PAM status
-
(Read only)
0x2552:006
general
P600.xx
PID setup
└ P600.01 Operating mode Inhibited [0] Selection list 0x4020:001 general
└ P600.02
PID process var.
Analog input 1 [1]
Selection list
0x4020:002
general
└ P600.03
PID speed range
100 %
0 ... 100 %
0x4020:003
general
└ P600.04
PID line speed
w/o speed.add. [0]
Selection list
0x4020:004
general
└ P600.05
Min speed lim
-100.0 %
-100.0 ... 100.0 %
0x4020:005
general
└ P600.06 Max speed lim 100.0 % -100.0 ... 100.0 % 0x4020:006 general
P601.00
PID P-component
5.0 %
0.0 ... 1000.0 %
0x4048
general
