Emotron VS10 - Page 61

Display code
Short designation
Default setting
Setting range
Address
Category
P602.00
PID Icomponent
400 ms
10 ... 6000 ms
0x4049
general
P603.00 PID D-component 0.0 s 0.0 ... 20.0 s 0x404A general
P604.00
PID setp.ramp
20.0 s
0.0 ... 100.0 s
0x404B
general
P605.xx
PID setp. limit
└ P605.01
Minimum setpoint
-300.00 PID unit
-300.00 ... 300.00 PID unit
0x404E:001
general
└ P605.02
Maximum setpoint
300.00 PID unit
-300.00 ... 300.00 PID unit
0x404E:002
general
P606.xx PID speed op.
└ P606.01
Accel. time
1.0 s
0.0 ... 3600.0 s
0x4021:001
general
└ P606.02
Decel. time
1.0 s
0.0 ... 3600.0 s
0x4021:002
general
P607.xx
PID influence
└ P607.01
Show time
5.0 s
0.0 ... 999.9 s
0x404C:001
general
└ P607.02 Mask out time 5.0 s 0.0 ... 999.9 s 0x404C:002 general
P608.xx
PID alarms
└ P608.01
MIN alarm thrsh.
0.00 PID unit
-300.00 ... 300.00 PID unit
0x404D:001
general
└ P608.02
MAX alarm thrsh.
100.00 PID unit
-300.00 ... 300.00 PID unit
0x404D:002
general
└ P608.03
Bandw. feedback
2.00 %
0.00 ... 100.00 %
0x404D:003
general
P610.xx PID sleep mode
└ P610.01
Activation
Disabled [0]
Selection list
0x4023:001
general
└ P610.02
Stop method
Coasting [0]
Selection list
0x4023:002
general
└ P610.03
Freq. thresh.
0.0 Hz
0.0 ... 599.0 Hz
0x4023:003
general
└ P610.04
Feedback thresh.
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4023:004
general
└ P610.05 Delay time 0.0 s 0.0 ... 300.0 s 0x4023:005 general
└ P610.06
Recovery
Setp. > P610.3 [0]
Selection list
0x4023:006
general
└ P610.07
Bandwidth
0.00 PID unit
0.00 ... 300.00 PID unit
0x4023:007
general
└ P610.08
Recovery thresh.
0.00 PID unit
-300.00 ... 300.00 PID unit
0x4023:008
general
P615.xx
Auto-rinsing
└ P615.01 Rinsing in idle Inhibited [0] Selection list 0x4024:001 general
└ P615.02
Rinse interval
30.0 min
0.0 ... 6000.0 min
0x4024:002
general
└ P615.03
Rinse speed
0.0 Hz
-599.0 ... 599.0 Hz
0x4024:003
general
└ P615.04
Rinse period
0.0 s
0.0 ... 6000.0 s
0x4024:004
general
P700.xx
Device commands
└ P700.01 Load def. sett. Off / ready [0] Selection list 0x2022:001 general
└ P700.03
Save user data
Off / ready [0]
Selection list
0x2022:003
general
└ P700.04
Load user data
Off / ready [0]
Selection list
0x2022:004
general
└ P700.05
Load OEM data
Off / ready [0]
Selection list
0x2022:005
general
└ P700.06
Save OEM data
Off / ready [0]
Selection list
0x2022:006
general
└ P700.07 Load par. set 1 Off / ready [0] Selection list 0x2022:007 general
└ P700.08
Load par. set 2
Off / ready [0]
Selection list
0x2022:008
general
└ P700.09
Load par. set 3
Off / ready [0]
Selection list
0x2022:009
general
└ P700.10
Load par. set 4
Off / ready [0]
Selection list
0x2022:010
general
└ P700.11
Save par. set 1
Off / ready [0]
Selection list
0x2022:011
general
└ P700.12 Save par. set 2 Off / ready [0] Selection list 0x2022:012 general
└ P700.13
Save par. set 3
Off / ready [0]
Selection list
0x2022:013
general
└ P700.14
Save par. set 4
Off / ready [0]
Selection list
0x2022:014
general
└ P700.15
Delete logbook
Off / ready [0]
Selection list
0x2022:015
general
P701.00
KP setp. incr.
1
1 ... 100
0x2862
general
P702.00 Scal.speed fact. 0.00 0.00 ... 650.00 0x4002 general
P703.00
KP status displ.
0x00000000
0x00000000 ... 0xFFFFFF00
0x2864
general
