Cordex®CXCHPControllerSoftwareManual|7-Invertersystems
configurationandthephaseangle.Thecommissionwizardstepstheuserthroughtheprocess.Oncethis
iscomplete,therewillbeoneinverter(perphase)inthesystem.
Important: Follow all wizard instructions: If a mistake is made during commissioning or the wizard
encounters an error, commissioning must start over.
Commissioning may take several minutes to complete. This process is complex due to several
factors:
1.
ThetypeofACinputsourceconnectionisunknown.TheACinputsourcemaybeconnectedas
singlephase,splitphase,2-pole,orthreephase.Thecontrolleridentifiesthecorrectconfiguration
oftheACinputandconfigurestheT2Sinvertercontrolleraccordingly.
2. Forthreephaseandsplitphaseconnection,theACphaserotationisunknown.Thismeansthatif
phase1isassumedtohaveaphaseangleof0degrees,phase2mayhaveaphaseangleof120
degreesor240degrees.Thecontrollerwillidentifythecorrectphaserotation.
3. TheinverterstaketimetosynchronizetotheACinput.Asthecontrollerprobesallpossible
combinationstheinverterstakeatleast30secondsaftereachcombinationbeforedeterminingif
theyhavesynchronizedtotheACinput.
OncethecorrectACinputconnectionandthephaseanglehavebeendetermined,theT2Sinverter
controllerisconfiguredcorrectlytoacceptmoreinverters.
Adding inverters
Thethirdstageofcommissioninginvolvesinsertingtherestoftheinverters.Thisprocesstakestime.Itis
recommendedthatyoufollowalltheinstructionswithinthewizard.
Whenaninverterisinserted,itlearnsitspowerconfigurationfromtheinvertersalreadyinsertedinthat
phase.Thecontrollersetsthevaluesforthefollowing:
•
ACinputgroup
• DCinputgroup
• ThelocationinformationofbayID,slotID,andshelfID
•
Thecorrectphasenumberandphaseshift.
Afterallinvertersareinsertedintotheshelves,thefinalstepistoconfiguretheT2Sinvertercontroller
withtheparametersforthenumberofmodulesperphase,andthenumberofredundantmodulesin
eachphase.Thisinformationisimportantforthecorrectoperationofalarmsassociatedwithredundancy,
missinginvertersorsystemoverload.
Important: After configuring and commissioning is successful, make a backup of the system from
the LCD via the Shortcuts > Backup menu. This allows the system configuration to be restored
in the event of a controller replacement.
0350058-J0 Rev AL Page 109
