Cordex®CXCHPControllerSoftwareManual|10-Distributionsystems
Thefirststepofthewizardthereisanoptiontonamethesubsystem.Next,specifythenumberofbreaker
orfusepanelstocreate.Thereisalimitof160breakersacrossallthepanels.Thiscouldconsistof160
panelswithonebreakereach,10panelswith16breakerseach,orsomeothercombination.Thereisan
optiontonameeachpanel,specifythenumberofbreakersorfuses,andspecifytheshuntconfiguration.
Whenfinishedyoucanstilladdorremovepanels,breakersandshuntsviatheirrespectivepagesinthe
subsystemtree.Afterpanels,breakersandshuntshavebeenadded,specifytherangesofalltheshunts
inthesubsystem.ThesecanbechangedlaterviatheShunts table.
Figure 10-3 Exampleofauserdefinedsubsystem
Distributionsubsystem(CXPS-C)
Breaker/fuse
Shunt
Upto24shunt+fusepositionsperbay
EachCXPS-CBayis onefusepanel
To create a user defined subsystem:
1. GotoSystems > Distribution System > Subsystems,selectCreate User Defined Subsystem,
andthenfollowthewizard.
2. IntheDistribution Subsystems table,selecttheGO TO buttontoviewthesubsystem.
3. Ifyouneedtomaptheshuntsources,gotoSystems > Distribution System > Subsystems >
Subsystem > Shunts,selectMap Shunts to ADIO Inputs,andthenfollowthewizard.
4. ShuntsandBreakers/Fusescanberemovedfromanyofthetableswherethesearelistedinthe
Subsystem.However,becausetheSubsystemneedstoknowtheparentpanelwhenaddingnew
ShuntsorBreakers/Fuses,theycanonlybeaddedfromtheSystems > Distribution System >
Subsystems > Subsystem > Subsystem Details > Downstream Loads > Panel > Shuntstable.
10.6. Configure the panel details
Apanelisagroupingofbreakersorfuseswithinasubsystem.Apanelisconsideredadownstreamload
ofasubsystem.Onsmartsubsystems,theseareautomaticallycreatedaccordingtothenumberofpanels
thattheADIOmodulesupports.ForBDFBdistributionsubsystems,thefulleightpanelsarecreated,even
thoughsomemaybelinkedorblank.ForSmartE2distributionsubsystems,twopanelsarecreated.Ona
userdefinedsubsystem,youcanadduptotenpanelspersubsystem.
Tomonitorabreakerorfusetripassociatedwithapanel,theBreaker/Fuse Source shouldbemapped
toadigitalinputaswell.Again,forsmartsubsystems,thesevaluesareautomaticallysetbasedonthe
assignedADIOmodule.
0350058-J0 Rev AL Page 131
