Cordex®CXCHPControllerSoftwareManual|20-Maintainingthecontroller
20.3.10. Change the dashboard values
ItispossibletochangethevaluesthatshowforasystemontheSystem Status Bar,theLCD
Dashboard,andtheWeb UI Dashboard.
To change which values appear for a system:
1. GotoController > Settings > User Interface.
2. Lookatthetableforthesystemyouwishtoconfigure(DCSystem48VDashboardValuesfor
example).
3.
SelecttheEDIT buttonbesidetheDashboard Value youwouldliketoedit.
Notice: The values in this table will appear on the different dashboards in the order they
appear in this table (for example, Dashboard Value 1, then Dashboard Value 2, ...). To
change the order, set the fields in this table in the desired order.
4. SelectthevaluetoshowforthisDashboard Value,thenselectSave.
ThenewvalueselectedwillappearinthepositionoftheDashboard Value thatwasconfigured.
20.3.11. Data sharing
TheDataSharingfeatureallowstoshareindividualdatapoint,orselectsystemsbetweencontrollers.
Thisdatasharingfeatureconsistsoftwoparts:
Publisheddata
Datasubscriptions
Datasharingcanbeusefulinsituationswheresystemswereinstalledatdifferenttimes.Thesesystems
mayhavedifferentcontrollers,butsharethesamebus(forexample,aDCsystemwasinstalled,then
later-on,anAMPSsystemwasinstalled,eachwiththeirowncontrollers).
Usingthisfeature,theAMPSsystemcontrollerprovidestheDCsystemcontrollerwithdataonhowmuch
DCinputcurrentitwillrequireduringanoutage.
TheDCsystemcontrollerprovidestheAMPSsystemcontrollerwithdataonhowmuchruntimethe
batteryhasremaining.
20.3.11.1. Share published data and systems
Eachcontrollercanpublishtendatapointsanduptofivesystemswhichothercontrollerscanreadand
useforvariouspurposes.
Notice: Currently the data points are limited to numeric data and only DC and AMPS HP2
systems can be published.
0350058-J0 Rev AL Page 189
