Cordex®CXCHPControllerSoftwareManual|24-Cordex®CXCHPcontrollerreferenceguide
Table 24-3 24voltsystemdefaultvaluesandranges(continued)
Setting name Default Minimum Maximum
OverVoltageProtection 28.5 24.25 31.5
AbsorptionVoltage 27.5 24.9 29.5
AbsorptionArmingVoltage 24 21 26.5
TempCompMaxVoltage 27.75 N/A 29
TempCompMinVoltage 26.25 23.75 N/A
BatteryStringNumberofCells 12 1 200
TempCompVoltageWarning 0.5 0 0.5
BatteryTestTerminationVoltage 22.25 22.25 26
OutputVoltageHighAlarm 27.75 21 30
OutputVoltageVeryHighAlarm 28.25 21 30
OutputVoltageLowAlarm 24 21 30
OutputVoltageVeryLowAlarm 23.25 18 30
24.3.3. 48 volt system default values and ranges
Thistableprovidesthedefaultvaluesandrangesfora48voltsystem.
Table 24-4 48voltsystemdefaultvaluesandranges
Setting name Default Minimum Maximum
AllowedVoltageRange N/A 42 60
FloatVoltage 54 47.5 58.2
EqualizeVoltage 55 49.8 60.2
BoostVoltage 55 49.8 60.2
Rectifier-MinimumTestVoltage 44 N/A N/A
SafeVoltage 51.4 46 56
OverVoltageProtection 57 48.5 63
AbsorptionVoltage 55 49.8 59
AbsorptionArmingVoltage 48 42 53
TempCompMaxVoltage 55.5 N/A 58
TempCompMinVoltage 52.5 47.5 N/A
BatteryStringNumberofCells 24 1 200
0350058-J0 Rev AL Page 275
