Cordex®CXCHPControllerSoftwareManual|10-Distributionsystems

Thereareseveraltextfieldsassociatedwithapanel,whichtheusermayfindusefultofurtherdescribe

thepanel,suchasDescription,FuseNumber,FuseSize,andFuseMaximumAmperage.Theseare

optionalandmaybefilledinbytheuserifdesired.

Therearethreealarmsprovidedoneachpanel:Breaker Trip,Loss of Feed,andOver Current.Ona

userdefinedsubsystem,thresholdsforthesealarmsaresetasapplicable.TheBreaker Trip alarmis

notathresholdalarm;itiscalculatedbasedontheBreaker/Fuse Source setforthepanel.Onasmart

subsystem,alarmscomedirectlyfromtheADIOmoduleandthresholdsmustbesetontheADIOmodule.

AconceptspecifictotheBDFBdistributionsystemislinkingpanels.Panelsmaybelinkeduptothepanel

above,orlinkeddowntothepanelbelow,basedontheloads.Theymayalsobesetblankifunused.

Whenoneormorepanelsarelinked,onemuststillbedesignatedastheshunt,andtheothersare

configuredaslinked.Thevoltageandcurrentmeasurementsaretakenfromtheshuntpanelonly.The

breakertripsarestillmonitoredonalllinkedpanels.Theconfigurationofpanelsasshunt,linkedup,

linkeddown,orblankmustbedoneviatheCordex®SmartBDFBiADIOmodule.Thecontrolleronly

reportsthedetails.

To configure panel details:

1. GotoSystems > Distribution System > Subsystems,andselecttheGO TO buttonforthe

subsystemthatcontainsthepanelstoconfigure.

2. EntertheSubsystem Details menu.

IntheDownstream Loads table,selecttheGO TO buttonforthepaneltoconfigure.

Notice: Note that in smart subsystems, the configuration is done automatically via ADIO

module.

4. IntheConfiguration table,editthedetailsofthepanel.

10.7. Configure the breaker or fuse details

Inadistributionsystem,abreakerorfuserepresentsadownstreamloadofapanel.Breaker/fuse

configurationcanbeaccesseddirectlyunderthesubsystem,orfromthepanelinwhichitresides.

WithintheBreaker/Fuseconfiguration,thereareanumberoftextfieldsthatcanbeusedtobetter

describeanddefinethebreakers.ThesecannotbeobtainedfromtheADIOmoduleinanyautomatic

way.Theyneedtobeconfiguredmanually.ThesefieldsincludeaDescription,Usage,Size,AWG,and

Destination fieldforeachbreaker.Manuallyeditingallofthesefieldsisalotofworkforlargesystems.

Themosteffectivewaytodothisistodownloadandeditthefieldsinspreadsheetformat.Thismakesit

easytocutandpaste,usemacros,orreuseenteredtextforotherpurposes(suchasprintinglabels).

Notice: The input source of the breaker is set automatically because the value is constrained by

physical wiring on the panel. Although the field is editable, it will be set back to the correct value if

it is manually changed. This is true for Smart E2 subsystems only.

Page 132 0350058-J0 Rev AL
