Cordex®CXCHPControllerSoftwareManual|20-Maintainingthecontroller
8. Whencomplete,selectFinish andthechangesareapplied.
9. Selectthebackarrow,ontheupper-leftsideofthescreentwiceandgobacktotheEthernet
screentoconfirmthenewsettings.
OntheEthernetscreen,verifythatthenewIPaddresssettingsareinuse.
20.1.1. Connect via the web interface
ToconfiguretheIPaddressesviathewebinterface:
1. Fromthemaindashboard,gotoController > Communication > Ethernet.
2. IntheEthernet table,selecttheGO TO buttonontherowyouwanttoconfigure.
3. IntheConfiguration table,selectChange Network Configuration andfollowthestepsinthe
wizard.
FromtheEthernet table,viewandverifythenewIPaddresssettings.
Notice: If you change the IP address that you are using, you will need to type the new IP address
into your browser so that you can log in again.
20.2. Working with alarms, alerts, and hints
20.2.1. Active alarms
Whenthereareactivealarmsinthesystem,boththeLCDandwebinterfacedisplaythesealarms
prominently.
Dependingonhowthealarmsareconfigured,aninternalspeaker(ifpresentandinstalled)maysoundan
alarmtone,andoneormorerelaysmaybeactivated.Theinternalspeakerisintendedtogivetheon-site
technicianaudiblenotificationthatanalarmisactive.Therelaysareintendedtogiveexternalmonitoring
equipmentnotificationthrougharelaycontactclosure(oropening)thatanalarmisactive.
OnboththewebinterfaceandtheLCD,thetopleftregionofthepagedisplaysthemostrecentalarms
inorderofthehighestpriority.Thisareaofthedisplaywillberedwhentherearecriticalormajoralarms,
yellowforminoralarms,andgreenifthereareonlywarningsornoalarms.Selectingthisregiontakesyou
totheActive Alarms tablewhereyoucangetmoredetails.
TheActive Alarms tabledisplaysthenameofthealarm,timeofactivation,priority,andstatus.The
statusofanactivealarmcanbeactiveoracknowledged.Analarmmovesfromtheactivetothe
acknowledgedstatewhenthealarmcut-off(ALCO)buttonispressed.TheALCObuttonisatthetopof
theActive Alarms table.
OnthewebinterfacethereisalsoasmallALCObuttonintheActive Alarms regionofthemain
dashboardthatwillacknowledgeanyactivealarms,andthentakeyoutotheActive Alarms list.
OntheLCD,ALCOcanalsobeaccessedviatheMaintenance buttononthemaindashboard.
Page 180 0350058-J0 Rev AL
