Figure 4-15 Dashboardusingwidedatapanelview
Toaccessthewidedatalayout,gotoController > Shortcuts > Dashboard Config > LCD Dashboard
Option > Wide Data Panel.Ifthereismorethanonesystemonthecontroller.SwitchingtoWide Data
Panel fromAutomatic isatwo-stepprocess.OnceWide Data Panel ischosen,aspecificsystemmust
beselectedsothatthedatavaluesdisplayforthatspecificsystem.
Language: ProvidesaccesstotheController > Settings > User Interface > LCD Preferences > LCD
Language setting,wherethelanguagefortheLCDcanbechangedtoanyoftheavailabletranslations.
Switchthelanguagebyselectingthedesiredlanguagefromthelistthenselectthecheckmark.Controller
supportsthreelanguagesEnglish(Imperial),English(Metric),andFrench.
Browse USB: ProvidesaccesstoanLCDonlyfunction,whichallowsyoutoviewthefilesonanyUSB
drivethatmaybeattachedtothecontroller.Ifafileisselectedfromthisview,theLCDgoestothe
availableactionscreenforthatfile–forexample,theLCDdisplaysanupgradescreenifanapplication
fileischosenfromtheUSB.
Notice: When using a USB drive with the controller, use a version 3.0 (or later) USB drive for best
reliability. Once inserted, it can take up to 20 seconds for the controller to recognize a USB drive.
Export diagnostic information: ProvidesanoptiontoexportaDiagnosticInformationPackage
containingimportantlogsandacontrollerclonetoaUSBdrive.Thisinformationisneededforany
supportrequests.Formoreinformationonhowtodownload,refertotheExporting Diagnostic
Information sectionofthismanual.
Figure 4-16 Exportdiagnosticinformation
Page 48 0350058-J0 Rev AL
