Cordex®CXCHPControllerSoftwareManual|24-Cordex®CXCHPcontrollerreferenceguide
Table 24-2 12voltsystemdefaultvaluesandranges
Setting name Default Minimum Maximum
AllowedVoltageRange N/A 10.5 15
FloatVoltage 13.5 11.875 14.55
EqualizeVoltage 13.75 12.45 15.05
BoostVoltage 13.75 12.45 15.05
Rectifier-MinimumTestVoltage 11 N/A N/A
SafeVoltage 12.85 11.5 14
OverVoltageProtection 14.25 12.125 15.75
AbsorptionVoltage 13.75 12.45 14.75
AbsorptionArmingVoltage 12 10.5 13.25
TempCompMaxVoltage 13.875 N/A 14.5
TempCompMinVoltage 13.125 11.875 N/A
BatteryStringNumberofCells 6 1 200
TempCompVoltageWarning 0.25 0 0.25
BatteryTestTerminationVoltage 11.125 11.125 15
OutputVoltageHighAlarm 13.875 10.5 15
OutputVoltageVeryHighAlarm 14.125 10.5 15
OutputVoltageLowAlarm 12 10.5 15
OutputVoltageVeryLowAlarm 11.625 9 15
24.3.2. 24 volt system default values and ranges
Thistableprovidesthedefaultvaluesandrangesfora24voltsystem.
Table 24-3 24voltsystemdefaultvaluesandranges
Setting name Default Minimum Maximum
AllowedVoltageRange N/A 21 30
FloatVoltage 27 23.75 29.1
EqualizeVoltage 27.5 24.9 30.1
BoostVoltage 27.5 24.9 30.1
Rectifier-MinimumTestVoltage 22 N/A N/A
SafeVoltage 25.7 23 28
Page 274 0350058-J0 Rev AL
