3-46 Phaser 5500 Printer Service Manual
9
Test the Exit 2 Sensor.
1. Open Door E.
2. Run the Service Diagnostics Exit Sensor
test.
Does the sensor change state?
For E4-5: Go to
Step 10.
For E4-3: Go to
Step 12.
Go to Step12.
10
For E4-5 Only:
Check Exit 2 Solenoid.
Check continuity on each wire between P/
J209 to P/J433.
Is there continuity on each wire
between
Go to Step 11. Repair the wiring.
11
For E4-5 Only:
Check for +24 V to the Exit 2 Gate
Solenoid.
Is there +24 V across P/J433-11 (+) <=>
ground?
Replace the Exit 2
Gate Solenoid
(
page 3-98).
Replace the Exit
PWB (
page 8-88).
12
Check the Exit Sensor connection.
Are P/J112, P/J606B, and P/J434
connected?
Go to Step 13. Connect the
sensor.
13
Check continuity between the Exit Sensor
and Exit PWB.
Is there continuity on each wire
between P/J112 <=> P/J434?
Go to Step 14. Repair the wiring.
14
Check for +5 V at the Exit Sensor.
Is there +5 V across the sensor
connector’s P/J112-3 <=> ground?
Replace the Exit 2
Sensor
(
page 3-102)
Go to Step 15.
15
Check the connection between the Exit
PWB and Engine Logic Board,
Are P/J431 and P/J421 connected?
Go to Step 16. Connect P/J431
and P/J421.
16
Check continuity between the Exit PWB
and the Engine Logic Board.
Is there continuity on each wire
between P/J431 <=> P/J421?
Go to Step 17. Repair the wiring.
17
Check the connection between the Exit
PWB and the LVPS.
Are P/J430 and P/J526 connected?
Go to Step 18. Connect P/J430
and P/J526.
18
Check continuity between the Exit PWB
and the LVPS.
Is there continuity on each wire
between P/J430 <=> P/J526?
Go to Step 19. Repair the wiring.
19
Check for +24 V to the Exit PWB.
Is there +24 V across P/J430-1 (+) <=>
ground?
Replace the Exit
PWB (
page 8-88).
Replace the
LVPS
(
page 8-92).
E4-3 Exit 2 Area Jam Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
