Error Messages, Codes, and Procedures 3-97
7
Check the H-’Xport Exit Sensor signal.
Does the voltage across J8372-5 <=>
J8372-4 on the H-’Xport PWB change
when the sensor actuator is operated?
Replace the H-
’Xport PWB
(
page 3-247).
Replace the H-
’Xport Exit
Sensor
(
page 3-118).
8
Test the H-’Xport Motor.
Run the Service Diagnostics H-’Xport
Motor test.
Does the motor rotate normally?
Go to Step 16. Go to Step 9.
9
Check the H-’Xport Motor connections.
Is the H-’Xport Motor correctly
connected to the harness?
Go to Step 11. Connect and go
to Step 10.
10
Print a Test Print.
Does the error still occur?
Go to Step 11. Problem solved.
11
Check the harness for continuity.
1. Disconnect P/J8379 of the H-’Xport
Motor, and P8372 on the H-’Xport PWB.
2. Check for continuity at the following:
P8372-13 <=> J8379-6
P8372-12 <=> J8379-4
P8372-11 <=> J8379-1
P8372-10 <=> J8379-3
P8372-15 <=> J8379-2
P8372-3 <=> J8379-5
Are these conductive?
Go to Step 12. Repair the
harness.
12
Check the H-’Xport Motor resistance.
Is there some amount of resistance
across P8379-2/5(COM) and P8379-1/3/
4/6?
Go to Step 13. Replace the H-
’Xport Motor
(
page 3-113).
13
Check for +24 V to the H-’Xport Motor.
Is there +24 V across J8372-15 <=>
J8372-7, and J8372-14 <=> J8372-7 on
the H-’Xport PWB?
Go to Step 14. Replace the H-
’Xport PWB
(
page 3-247).
14
Replace the H-’Xport Motor.
Print a Test Print.
Does the error still occur?
Go to Step 15. Problem solved.
15
Replace the H-’Xport PWB.
Print a Test Print.
Does the error still occur?
Go to Step 16. Problem solved.
16
Test the X'port Entrance Sensor.
Run the Service Diagnostics Finisher
Transport Entrance Sensor test.
Does the sensor state change?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 17.
Jam at F (Transport Entrance Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
