Error Messages, Codes, and Procedures 3-113
6
Print a Test Print.
Does the error still occur?
Go to Step 7. Problem solved.
7
Check Buffer Sensor Harness continuity.
1. Disconnect P/J8392 and P/J8318.
2. Check for continuity at the following:
P/J8392-3 <=> J8318B-1
P/J8392-2 <=> J8318B-2
P/J8392-1 <=> J8318B-3
Are these conductive?
Go to Step 8. Repair the Buffer
Sensor Harness.
8
Check Main Sensor Harness continuity.
1. Disconnect P/J8318 from the harness,
and P/J8302A on the Finisher Main
PWB.
2. Check for continuity at the following:
J8318A-3 <=> P/J8302A-13
J8318A-2 <=> P/J8302A-14
J8318A-1 <=> P/J8302A-15
Are these conductive?
Go to Step 9. Repair the Main
Sensor Harness.
9
Check for +5 V to the Buffer Path Sensor.
Is there +5 V across J8302A-15 <=>
J8302A-13 on the Finisher Main PWB?
Go to Step 10. Replace the
Finisher Main
PWB
(
page 3-248).
10
Check the Buffer Path Sensor signal.
Does the voltage across P8302A-14 <=>
P8302A-13 on the Finisher Main PWB
change when the actuator is operated?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the
Buffer Path
Sensor
(
page 3-207).
11
Test the Registration Motor.
Run the Service Diagnostics Registration
Motor CCW Test.
Does the motor rotate normally?
Go to Step 20. Go to Step 12.
12
Test the Buffer Roller Drive.
Run the Service Diagnostics Registration
Motor CCW test.
Does the Buffer Roller rotate?
Go to Step 14. Restore operation
and go to
Step
13.
13
Print a Test Print.
Does the error still occur?
Go to Step 14. Problem solved.
14
Check the Registration Motor harness
connections.
Are P/J8335 and P/J8304 connected?
Go to Step 16. Connect and go
to Step 15.
15
Print a Test Print.
Does the error still occur?
Go to Step 16. Problem solved.
Jam at F or G (Compile Exit Sensor ON) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
