3-116 Phaser 5500 Printer Service Manual
Static Jam at H (Compile Exit Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Test the Compile Exit Sensor.
Run the Service Diagnostics Compile Exit
Sensor test.
Does the sensor state change?
Go to Step 10. Go to Step 2.
2
Check the Compile Exit Sensor
connection.
Are P/J8320 and P/J8391 connected?
Go to Step 4. Connect and go
to Step 3.
3
Print a Test Print.
Does the error still occur?
Go to Step 4. Problem solved.
4
Check Main Sensor Harness connections.
Are P/J8391 and P/J8302A connected?
Go to Step 6. Connect and go
to Step 5.
5
Print a Test Print.
Does the error still occur?
Go to Step 6. Problem solved.
6
Check Compiler Harness continuity.
1. Disconnect P/J8320 and P/J8391.
2. Check for continuity at the following:
P/J8320A-3 <=> J8391B-1
P/J8320A-2 <=> J8391B-2
P/J8320A-1 <=> J8391B-3
Are these conductive?
Go to Step 7. Repair the
Compiler
Harness.
7
Check Main Sensor Harness continuity.
1. Disconnect P/J8391 from the harness,
and P/J8302A on the Finisher Main
PWB.
2. Check for continuity at the following:
J8391A-3 <=> P/J8302A-4
J8391A-2 <=> P/J8302A-5
J8391A-1 <=> P/J8302A-6
Are these conductive?
Go to Step 8. Repair the Main
Sensor Harness.
8
Check for +5 V to the Compile Exit Sensor.
Is there +5 V across J8302A-6 <=>
J8302A-4 on the Finisher Main PWB?
Go to Step 9. Replace the
Finisher Main
PWB
(
page 3-248).
9
Check Compile Exit Sensor signal.
Does the voltage across P8302A-5 <=>
P8302A-4 on the Finisher Main PWB
change when the actuator is operated?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the
Buffer Path
Sensor
(
page 3-207).
10
Test the Exit Motor.
Run the Service Diagnostics Finisher Exit
Motor Test.
Does the motor rotate normally?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 11.
