Fuji Xerox Phaser 5500

Parts Lists 9-11
Parts List 2.2 Tray 2/2
No. Name/Description Part Number
1 TRAY ASSEMBLY (with 2~26) 109R00733
2 TRAY COVER
3 -
4 LABEL (MAX)
5 BOTTOM PAD
6 FRONT SIDE GUIDE
7 -
8 TRAY PAD
9 REAR SIDE GUIDE
10 BOTTOM PLATE
11 TRAY
12 SIDE GUIDE ACTUATOR
13 GUIDE ACTUATOR
14 SPRING
15 PINION GEAR
16 END GUIDE
17 SPRING
18 END GUIDE ACTUATOR
19 LINK
20 COUPLING GEAR (13T)
21 GEAR (13T/60T)
22 SECTOR GEAR (60T)
23 BRACKET
24 LIFT UP SHAFT
25 STOPPER
26 SEAL
99 KIT, LABEL
