Fuji Xerox Phaser 5500

Parts Lists 9-13
Parts List 2.3 Feeder 2/2
No. Name/Description Part Number
1 FEEDER ASSEMBLY (with 2~50) 059K26934
2 TRAY FEED LIFT UP MOTOR 127K38170
3 BRACKET
4 SPACER
5 GEAR (31T)
6 SPRING
7 ONEWAY CLUTCH
8 ONEWAY GEAR
9 GEAR (13T)
10 BEARING
11 SHAFT
12 FRONT CHUTE
13 ACTUATOR (No Paper Sensor Actuator) 120E22481
14 SENSOR (No Paper or Level Sensor) 930W00113
15 SENSOR (Pre-Feed Sensor) 930W00211
16 WIRE HARNESS
17 GEAR (28T/21T)
18 GEAR (29T)
19 SPRING 809E51070
20 ROLLER ASSY--Periodic replacement part per 300k prints (included
with 99) (Feed Roller)
21 ONEWAY CLUTCH
22 ONEWAY GEAR (22T)
23 SHAFT
24 CHUTE
25 SPRING
26 FRICTION CLUTH
27 SHAFT-RETARD
28 --
