Parts Lists 9-19
Parts List 3.2 Tray 1/MPT Lower Frame Assembly
No. Name/Description Part Number
1 FRAME ASSY LOWER (with 2~28)
2 FRAME LOWER MSI
3 STOPPER LEVER
4 COLLAR
5 SHAFT-RETARD
6 GEAR PICK UP
7 GEAR 18T
8 LEVER-GEAR
9 BEARING 8
10 PAD BOTTOM 019E56551
11 PLATE BOTTOM
12 PAD ASSY-RETARD 019K07085
13 GUIDE PAPER MSI
14 ROLL ASSY-DRIVE
15 SOLENOID PICK UP 121E92780
16 SHAFT ASSY PICK UP
17 CAM PICK UP 2 008E93831
18 CAM PICK UP FRONT 008E94270
19 ROLL CORE
20 ROLLER ASSY-FEED (Feed Roller with installation instructions) 604K23380
21 BEARING SLEEVE
22 GEAR CAM
23 SPRING LEVER GE
24 SPRING PAD (Retard Pad Spring) 809E27650
25 SPRING N F
26 SPRING-GEAR CAM 809E54530
27 PLATE EARTH BOTTOM
28 PLATE EARTH FRONT
