10-4 Phaser 5500 Printer Service Manual
202 E-180 Connects the Tray 3 Feed/Lift Motor and Tray 2 Feeder Harness.
204 H-199 Connects the Takeaway Clutch and PH Harness.
205 D-151 Connects the Tray 1/MPT Feed Solenoid and MSI Harness.
206 G-196 Connects the Exit 1 Offset Motor and EXIT Harness.
214 G-198 Connects the Drive Assembly and Drive Harness.
215 E-166 Connects the Registration Clutch and Registration Harness.
216 H-106 Connects the Toner Dispense Motor and LV PWR Harness.
221 E-107 Connects the Engine Logic Board and Drum Cartridge Fan.
311 B-242 Connects the Front Panel and Front Panel Harness.
400 C-214 Connects the Engine Logic Board and LV PWR Harness.
401 C-214 Connects the Engine Logic Board and LV PWR Harness.
402 D-212 Connects the Engine Logic Board and I/P Board Harness.
403 F-211 Connects the Engine Logic Board and Registration Harness.
404 E-212 Connects the Engine Logic Board and Xerographics Harness.
405 G-212 Connects the Engine Logic Board and Interlink Harness.
406 D-212 Connects the Engine Logic Board and Laser Harness.
407 C-212 Connects the Engine Logic Board and Laser Harness.
408 G-211 Connects the Engine Logic Board and Drive Harness.
409 G-213 Connects the Engine Logic Board and Feeder Harness.
410 G-212 Connects the Engine Logic Board and PH Harness.
411 G-214 Connects the Engine Logic Board and Tray 1/MPT Harness.
412 C-213 Connects the Engine Logic Board and Size Harness.
413 D-214 Connects the Engine Logic Board and Tray 4-5 Harness.
414 F-214 Connects the Engine Logic Board and Tray 6 Harness.
415 F-214 Connects the Engine Logic Board and Tray 6 Harness.
416 D-214 Connects the Engine Logic Board and Output Unit.
417 E-214 Connects the Engine Logic Board and Duplex Unit Harness.
419 D-212 Connects the Engine Logic Board and CRUM Harness.
Print Engine Plug/Jack Designators
P/J Coordinates Remarks
