A-4 Phaser 5500 Printer Service Manual
Service Diagnostics Menu Map
The Service Diagnostic Menu Map lists all the tests and utilities available within
Service Diagnostics. To access a test or utility, select the test type (motor, sensor,
solenoid), the specific part (Duplex Unit, Exit 2, Finisher), then the individual test.
For example, to access the list of Finisher motor tests, first select Motor/Fans, then
select the Finisher.
Service Diagnostics Tests
Print Service Menu Map This prints a 3-page Service Diagnostics Menu Map.
General Status
Provides current print engine
and option firmware version
and counter values.
Printer Version
Duplex Version
Exit Version
Trays 4 & 5 Feeder Version
Finisher Version
Tray 6 Feeder Version
Total Print Count
Transfer Roller Count
Drum Cartridge Count
Drum Cartridge Cycles
Tray 1/MPT Feed Count
Tray 2 Feed Count
Tray 3 Feed Fount
Tray 4 Feed Count
Tray 5 Feed Count
Tray 6 Feed Count
Test Print
Starts the Test Print.
Print Pattern
Print Quantity
Input Tray
Output Tray
Duplex
Staple Selection
Pages Per Set
Punch Selection
Select Pattern
Printer NVRAM Adjustments
Perform NVRAM adjustment
essential to the performance
of the printer.
Scan Direction All Trays
Scan Direction Tray 1/MPT
Scan Direction Tray 2
Scan Direction Tray 3
Scan Direction Tray 4
Scan Direction Tray 5
Scan Direction Tray 6/HCF
Scan Direction Duplex All Trays
Scan Direction Duplex Tray 1/MPT
Scan Direction Duplex Tray 2
Scan Direction Duplex Tray 3
Scan Direction Duplex Tray 4
Scan Direction Duplex Tray 5
Scan Direction Duplex Tray6/HCF
