Fuji Xerox Phaser 5500 User Manual

Reference A-5
Printer NVRAM Adjustments
Perform NVRAM adjustment
essential to the performance
of the printer.
Process Direction All Trays
Process Direction Tray 1/MPT
Process Direction Tray 2
Process Direction Trays 3-6
Process Direction Duplex All Trays
Motor/Fans Tests
Print Engine Motor Tests:
Tests motor/fans functionality.
Printer Main Motor On
Fuser Fan Motor High
Drum Fan Motor
Laser Scan Motor
Tray 2 Lift Motor
Tray 2 Feed Motor
Tray 3 Lift Motor
Tray 3 Feed Motor
Drum Cartridge Motor On
Offset Output Motor 1 Front
Offset Output Motor 1 Rear
Toner Dispense Motor
Duplex Assembly Motor
Test
Duplex Motor
Exit 2 Assembly Motor Tests Offset Output Motor 2 Front
Offset Output Motor 2 Rear
Exit Output Motor 2 Forward
Exit Output Motor 2 Reverse
Exit 2 Fan
Trays 4 & 5 Motor Tests Tray 4 Lift Motor
Tray 4 Feed Motor
Tray 5 Lift Motor
Tray 5 Feed Motor
Take Away Drive Motor
Tray 6 Motor Tests Tray 6 Lift Motor
Tray 6 Feed Motor
Tray 6 Take Away Motor-Slow
Tray 6 Take Away Motor-Fast
Finisher Motor Tests Horizontal Transport Motor-Fast
Horizontal Transport Motor-Slow
Transport Motor
Registration Motor-Fast-CW
Registration Motor-Slow-CW
Registration Motor- CCW
Exit Motor-Fast-CW
Exit Motor-Slow-CW
Exit Motor-CCW
Punch Unit Motor Front
Punch Unit Motor Rear
Punch Motor - 3 hole
Punch Motor - 2 hole
Punch Motor - 4 hole
