A-6 Phaser 5500 Printer Service Manual
Finisher Motor Tests Front Tamper Motor
Motor Low Speed Outboard
Motor Mid Speed Outboard
Motor High Speed Outboard
Motor Low Speed Inboard
Motor Mid Speed Inboard
Motor High Speed Inboard
Rear Tamper Motor
Motor Low Speed Outboard
Motor Mid Speed Outboard
Motor High Speed Outboard
Motor Low Speed Inboard
Motor Mid Speed Inboard
Motor High Speed Inboard
Staple Head Move Motor
Motor Low Speed Front
Motor Medium Speed Front
Motor High Speed Front
Motor Low Speed Rear
Motor Medium Speed Rear
Motor High Speed Rear
Stapler Motor Forward
Stapler Motor Reverse
Eject Clamp Motor - Up
Eject Clamp Motor - Down
Eject Motor
Motor Low Speed Forward
Motor High Speed Forward
Motor Low Speed Reverse
Motor High Speed Reverse
Stacker Motor - Up
Stacker Motor - Down
Printer Sensor/Switch Tests
Print Engine Sensor/Switch
Tests:
Tests the function of sensors/
switches by manually toggling
each sensor/switch.
Door A Interlock Switch
Door B Interlock Switch
Front Cover Interlock Switch
Tray 1/MPT Size Sensor (displays paper size for tray)
Tray 2 Size Sensor (displays paper size for tray)
Tray 3 Size Sensor (displays paper size for tray)
Tray 1/MPT No Paper Sensor
Tray 2 No Paper Sensor
Tray 3 No Paper Sensor
Tray 2 Level Sensor
Tray 3 Level Sensor
Tray 2 Pre-Feed Sensor
Tray 3 Pre-Feed Sensor
Tray 3 Feed Out Sensor
Registration Sensor
Fuser Exit Sensor
Standard Output Tray Full Sensor
Exit Offset 1 Home Position Sensor
Detect Drum Cartridge Switch
Duplex Sensor/Switch Tests Door D Interlock Switch
Wait Sensor
Service Diagnostics Tests (Continued)
