Fujitsu PRIMERGY RX300 S7 - Removing a BBU from the Air Duct; Removing the BBU from the BBU Holder

238 Upgrade and Maintenance Manual RX300 S7
Expansion cards and backup units
9.5.3.3 Removing a BBU from the air duct
Ê Remove the BBU module from the air duct as described in section
"Removing a BBU" on page 234.
9.5.3.4 Removing the BBU from the BBU holder
Figure 106: Removing the BBU from the BBU holder
Ê Press out on the right retaining bracket on the BBU holder (1) to disengage
the locking mechanism while pulling up the BBU (2).
