Fujitsu PRIMERGY RX300 S7 - Removing an RDX;DAT Drive out of the Cage

RX300 S7 Upgrade and Maintenance Manual 367
Accessible drives
Figure 214: Removing the cables from the RDX/DAT drive
Ê Disconnect the power adapter cable from the RDX/DAT drive (1).
Ê Disconnect the USB cable from the RDX/DAT drive (2).
12.9.4 Removing an RDX/DAT drive out of the cage
Figure 215: Removing the 4 screws
Ê Remove the 4 screws from the drive cage
