254 Upgrade and Maintenance Manual
RX300 S7
Expansion cards and backup units
Ê "Closing the rack door" on page 84
Ê If applicable, update the firmware of the RAID controller that has been
connected to the FBU as described in section "Updating RAID controller
firmware" on page 96.
Ê "Enabling SVOM boot watchdog functionality" on page 101
9.7 Additional tasks
This section provides additional expansion card related information on how to
install slot brackets and SFP+ transceiver modules.
I For further instructions regarding controller settings, please refer to the
accompanying documentation.
9.7.1 Mounting expansion card slot brackets
This section provides general instructions on mounting slot brackets as well as
specific instructions for the following network adapters:
●
"Network adapter D2735" on page 255
●
"Network adapter D2745" on page 257
●
"Network adapter D2755" on page 259
●
"USB 3.0 interface card D3305" on page 261
9.7.1.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Mounting slot brackets:
– Phillips PH2 / (+) No. 2 screw driver
Upgrade and Repair Units (URU)
Average task duration: 5 minutes
