RX300 S7
Upgrade and Maintenance Manual 479
System board and components
14.3.2.4 Concluding steps
Perform the following procedures:
Ê "Installing the air duct" on page 74
Ê "Mounting the server cover" on page 76
Ê "Sliding the server into the rack" on page 80
If the server has been completely removed from the rack for maintenance
purposes, reinstall and secure it in the rack as described in section
"Mounting the server in the rack" on page 77.
Ê "Connecting the server to the power source" on page 81
Ê "Closing the rack door" on page 84
14.3.3 Replacing the TPM board
V CAUTION!
Advise your contact persons that they must provide you with TPM
backup copies. For security reasons, the TPM must be restored/re-
saved by the customer. After installing a new system board, the TPM
must be enabled. You may not clear the TPM data.
If the contact persons DO NOT have a backup copy available, inform
them that replacing the TPM board will cause to lose all data.
14.3.3.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
●
Replacing the TPM:
– Bit screw driver
Field Replaceable Units (FRU)
Average task duration: 40 minutes
