Fujitsu PRIMERGY RX300 S7 - SAS Cabling

500 Upgrade and Maintenance Manual RX300 S7
Conversion configurations
15.1.2 SAS cabling
5
8x 2.5-inch
HDD +RDX
n.a.
6
8x 2.5-inch
HDD + LTO
n.a.
7
12x 2.5-
inch HDD
8
16x 2.5-inch
HDD
S26361-F1373-L378
8
16x 2.5-
inch HDD
n.a.
Config Cable from to
1 C8 X1 - 6x 3.5-inch HDD Bpl MLC1 -SAS controller
C9 X2 - 6x 3.5-inch HDD Bpl MLC2 -SAS controller
2 C10 X1 - 4x 2.5-inch HDD Bpl SAS1-4 system board
2 (with
controller)
C10 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
3 C10 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
4 C9 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
C10 X1 - 4x 2.5-inch HDD Bpl MLC2 -SAS controller
5 C8 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
C10 X1 - 4x 2.5-inch HDD Bpl MLC2 -SAS controller
6 C10 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
C11 X1 - 4x 2.5-inch HDD Bpl MLC2 -SAS controller
7 C9 X1 - 12x 2.5-inch HDD Bpl MLC1 -SAS controller
C9 X2 - 12x 2.5-inch HDD Bpl MLC2-SAS controller
8 C7 X1 - 4x 2.5-inch HDD Bpl X3 - 12x 2.5-inch HDD Bpl
C9 X1 - 12x 2.5-inch HDD Bpl MLC1 -SAS controller
C9 X2 - 12x 2.5-inch HDD Bpl MLC2 -SAS controller
