Fujitsu PRIMERGY RX300 S7 - 17 Appendix; Mechanical Overview; Server Front

RX300 S7 Upgrade and Maintenance Manual 541
17 Appendix
17.1 Mechanical overview
17.1.1 Server front
Front side overview
Figure 357: Server front side
Pos. Component
1 LSD module
2 Front panel module
3 Optical disk drive
4
Space for hard disc drives and backup drives (depending on the
configuration)
