Ê Press the Indicate CSS button (1) to highlight defective components.
Component LEDs
I LEDs A, B and C are visible from the outside on the server rear. All other
LEDs are only visible if the server cover has been opened. In order to
access fan LEDs
(O), the fan modules need to be removed
(see s
ection "Removing a fan module" on page 179).
Indicator Status Description
A Identification
blue on
server has been highlighted using the ID
button on the front panel for easy
identification
blue
flashing
server has been highlighted using IRMC
(AVR) when local VGA off for easy
identification
B
CSS
(Customer Self
Service)
off no critical event (CSS component)
yellow on prefailure detected (CSS component)
yellow
flashing
CSS component failure
C
GEL
(Global Error
LED)
off no critical event (non CSS component)
orange on
prefailure detected (non CSS
component)
orange
flashing
non CSS component failure
Possible reasons:
– sensors report overheating
– sensor is defective
– CPU error
– software reports an error
F Controller orange on controller faulty
G CPU orange on CPU faulty
H
Memory
module
orange on memory module faulty
I PS CTRL OK green on power supply OK
K PS CTRL Error orange on powe supply error
L Main power green on voltage ok
