120 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
6.3 Redundant power supply
6.3.1 Installing hot-plug power supply units
6.3.1.1 Preliminary steps
No steps needed.
6.3.1.2 Removing the PSU dummy cover
Figure 49: Removing a PSU dummy cover (A)
Ê Press in on both release latches (1) and remove the dummy cover (2).
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
