TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 289
Accessible drives and LSD
12.5 Slimline ODD and LSD in Multibay box
12.5.1 Installing the slimline ODD or LSD
12.5.1.1 Preliminary steps
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
I The front cover only needs to be removed in order to remove or install
accessible drive dummy covers. If the Multibay box is already
installed in the server and will be removed in order to install a slimline
ODD or LSD module, the front cover can remain installed.
Ê "Removing the system fan holder" on page 76
Ê "Removing the Multibay box" on page 296 (if applicable)
12.5.1.2 Installing the slimline ODD
Ê Press up on the locking tab to disengage the slimline ODD dummy module
as shown in figure 212 on page 297.
Ê From inside the Multibay module, press out on the ODD dummy module and
pull it out of its bay.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
