TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 157
Hard disk drives / solid state drives
Ê While keeping the locking tabs pressed, pull the dummy module out of its
bay (2).
V CAUTION!
Save the dummy module for future use.
Always replace dummy modules into unused HDD bays to comply
with applicable EMC regulations and satisfy cooling requirements.
7.3.4.3 Installing a 3.5-inch HDD module
Figure 84: Opening the 3.5-inch HDD module locking lever
Ê While pressing down on the locking button (1) fold up the lever (2).
