306
Upgrade and Maintenanc
e Manual
TX150 S8 / TX200 S7
Accessible drives and LSD
12.6.1.3
Inst
alling th
e LSD
Figure 223: Removing the LSD dummy cover plate (A)
Ê
Carefully bend out the LSD dummy cover plate (1) and disengage it
s right
edge (2).
Figure 224: Removing the LSD dummy cover plate (B)
Ê
Fold out (1) and remove (2) the LSD cover plate.
