Fujitsu PRIMERGY TX150 S8

To Next Page

To Previous Page

TX150 S8 / TX200 S7

Upgrade and Maintenance Manual 417

Appendix

17.1.2 Server rear

Figure 329: Rear side

1 Power supply unit (photo shows the standard power supply unit)

2 I/O panel

3 Optional expansion cards
