188 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
8.2 System fans
8.2.1 Replacing the system fans
I The system fans are installed in the system fan holder. Only the complete
system fan holder can be replaced as spare part.
8.2.1.1 Preliminary steps
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
Ê "Removing the system air duct" on page 63
8.2.1.2 Removing the defectice system fans
Ê Remove the system fan holder as described in section "Removing the
system fan holder" on page 76.
8.2.1.3 Installing the new system fans
Ê Install the system fan holder as described in section "Installing the system
fan holder" on page 77.
8.2.1.4 Concluding steps
Ê "Installing the system air duct" on page 64
Ê "Reassembling" on page 64
Ê "Connecting the server to the mains" on page 74
Ê "Switching on the server" on page 75
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: tool-less
