TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 403
16 Cabling
Safety notes
V CAUTION!
●
Always hold cables by their connectors when disconnecting them.
Never pull on the cable to disconnect cables.
●
Ensure that none of the cables are scraped, strained or otherwise
damaged while replacing system components.
●
Immediately replace cables with damaged shielding.
●
Always use shielded network cables.
16.1 List of used cables
I The numbers in the cable list correspond to those shown in the cabling
plans.
No. Name
Part number
(T26139-)
Routing
C1 CBL_PDB_MoBo_HDD_Pow Y4030-V101
Power backplane to system board
and HDD backplane
C2 CBL_PDB_MoBo_Pow14 Y3952-V511 Power backplane to system board
C3 CBL_PDB_MoBo_Pow12 Y4030-V2 Power backplane to system board
C4 CBL_PDB_MoBo_Sig10 Y3956-V2 Power backplane to system board
C5 CBL_MoBo_DVD Y3939-V301
ODD to system board or SAS
backplane
C6 CBL_MoBo_HDD Box_Pow Y3939-V401
System board to HDD extension
box
C10 CBL_FRONTPANEL 650 Y4015-V2
Front panel module to system
board
C12 CBL_INTRUSION_SW_New Y3922-V121
Server side and front to system
board
C17 CBL_LSD 700 Y3718-V301 LSD to system board
C19 CBL_FrontLAN 600 Y4025-V1 Server front to front LAN board
C20 CBL_SAS470x1 Y3963-V103 SAS backplane to SAS controller
Table 5: List of used cables
