316 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
Accessible drives and LSD
12.7 Slimline ODD in 4x 3.5-inch HDD extension
box
12.7.1 Installing the slimline ODD
12.7.1.1 Preliminary steps
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
I The front cover only needs to be removed in order to remove or install
accessible drive dummy covers. If the HDD extension box is already
installed in the server and will be removed in order to install a slimline
ODD or LSD module, the front cover can remain installed.
Ê "Removing the system fan holder" on page 76
Ê "Removing an HDD extension box" on page 179 (if applicable)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
