TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 301
Accessible drives and LSD
12.5.3 Replacing a slimline ODD or LSD
12.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 47
Ê "Removing backup and optical disk media" on page 82
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
I Removing the front cover is not required in order to replace the
slimline ODD or LSD module in the Multibay box.
Ê "Removing the system fan holder" on page 76
Ê "Removing the Multibay box" on page 296
12.5.3.2 Removing the defective slimline ODD
Ê Remove the slimline ODD from the Multibay box as described in section
"Removing the slimline ODD" on page 297.
12.5.3.3 Removing the defective LSD module
Ê Remove the LSD module from the Multibay box as described in section
"Removing the LSD module" on page 299.
12.5.3.4 Installing the new slimline ODD
Ê Install the slimline ODD into the Multibay box as described in section
"Installing the slimline ODD" on page 289.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
