TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 163
Hard disk drives / solid state drives
7.3.6.2 Removing a 3.5-inch HDD module
Ê Remove the HDD module to be replaced from the server as described in
section "Removing a 3.5-inch HDD module" on page 160.
7.3.6.3 Installing a 3.5-inch HDD module
Ê Install the new HDD module into the empty drive bay as described in section
"Installing 3.5-inch HDD modules" on page 156.
7.3.6.4 Concluding steps
Ê "Installing accessible drive and HDD bay covers" on page 71
Ê "Performing a RAID array rebuild" on page 101
7.3.7 Replacing a 3.5-inch HDD SAS backplane
7.3.7.1 Preliminary steps
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
Ê "Removing the system fan holder" on page 76
Ê "Removing 3.5-inch HDD modules" on page 159
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
