224 Upgrade and Maintenance Manual TX150 S8 / TX200 S7
Expansion cards and backup units
9.5.2 Installing a BBU
V CAUTION!
For further safety information, please refer to chapter "Important
information" on page 35.
9.5.2.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 80
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
9.5.2.2 Connecting the BBU cable to the BBU
Figure 150: Connecting the BBU cable
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
