64 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
Basic hardware procedures
4.5 Reassembling
V CAUTION!
●
Before attaching the covers, make sure no unnecessary parts or tools
are left inside the server.
●
In order to comply with applicable EMC regulations (regulations on
electromagnetic compatibility) and satisfy cooling requirements, the
server must not run while the top / side cover is removed.
●
For further safety information, please refer to chapter "Important
information" on page 35.
4.5.1 Installing the system air duct
Figure 17: Installing the system air duct
Ê Hold the system air duct by the two green touch points and lower it into the
chassis until the green locking latch clicks in (see close-up).
