Fujitsu PRIMERGY TX150 S8 - Installing an FBU; Preliminary Steps; Installing TFM to the RAID Controller (if Applicable)

TX150 S8 / TX200 S7 Upgrade and Maintenance Manual 229
Expansion cards and backup units
9.5.3 Installing an FBU
V CAUTION!
For further safety information, please refer to chapter "Important
information" on page 35.
9.5.3.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 80
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
9.5.3.2 Installing TFM to the RAID controller (if applicable)
Figure 154: TFM kit
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
1 TFM 2 Screws
