TX150 S8 / TX200 S7 Upgrade and Maintenance Manual 155
Hard disk drives / solid state drives
Figure 81: Mounting order with up to 8 3.5-inch HDDs (2 SAS backplanes) - Tower version
7.3.3.2 HDD / SSD naming scheme
Figure 82: Naming scheme with 8 3.5-inch HDDs (2 SAS backplanes) - Rack version
Position
Logical drive
number
ServerView RAID Manager display name
[1] 0 HDD vendor name (1:0)
[2] 1 HDD vendor name (1:1)
[3] 2 HDD vendor name (1:2)
[4] 3 HDD vendor name (1:3)
[5] 4 HDD vendor name (1:4)
[6] 5 HDD vendor name (1:5)
[7] 6 HDD vendor name (1:6)
[8] 7 HDD vendor name (1:7)
