428 Upgrade and Maintenance Manual TX150 S8 / TX200 S7
Appendix
I The meaning of further buttons is described in the corresponding
operating manual.
17.3 Onboard settings
Figure 338: Onboard settings
11
Power-on
indicator
green on server is switched on and running
orange on
server is switched off, but mains voltage
is present (standby mode)
Jumper Setting Description
SKP RCVR
Default Password delete and Recovery BIOS options
disabled
Password Skip
enabled
This jumper setting will permanently delete
the current BIOS password and apply default
BIOS settings.
Recovery BIOS
enabled
Recovery BIOS enabled
Pos. Indicator Status Description
SKU Key
INDICATE
CSS
Battery
FAN 1
FAN 3
FAN 2
TPM
UFM
MLC1
1
WP
SATA 1
SATA 2
USB 2 USB 1
HDD LED
Front Panel
P5
PCH
SMB
Intrusion
switch
P3
iRMC
Slot 1 PCI 32/33
Slot 2 PCIe x4 (x8 conn)
Slot 3 PCIe x4 (x8 conn)
Slot 4 PCIe x16
Slot 5 PCIe x4 (x8 conn)
1
st
RAID
2
nd
RAID
SKP RCVR
Password Skip
enabled
Setting
SKP RCVR
Password Skip/
Recovery BIOS
Jumper Description
WP
BIOS Write
Protect
1
Default
1 1
Recovery BIOS
enabled
Default (no jumper)
BIOS Write Protect
enabled
Jumper settings
