TX150 S8 / TX200 S7 Upgrade and Maintenance Manual 427
Appendix
I In addition to local diagnostic indicators, CSS or Global Error LEDs
indicate, if the defective component is a customer replaceable unit or if a
service technician needs to be dispatched to replace the part.
Status indicators
3
Temperature
error indicator
orange on
Operating temperature levels above
permitted limits
4
CPU error
indicator
orange on CPU prefailure event detected
5
Memory error
indicator
orange on Memory module failure detected
6
Fan error
indicator
orange on Fan prefailure or failure event detected
Pos. Indicator Status Description
7 ID indicator blue on
server has been highlighted using
ServerView Operations Manager or the
ID button on the front panel for easy
identification
8 CSS indicator
off no critical event (CSS component)
yellow on prefailure detected (CSS component)
yellow
flashing
CSS component failure
9
Global error
indicator
off no critical event (non CSS component)
orange on
prefailure detected (non CSS
component)
orange
flashing
non CSS component failure
10
HDD / SSD
activity
indicator
green
flashing
data access in progress
Pos. Indicator Status Description
