TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 195
8.3.3 Replacing the rear fan
8.3.3.1 Preliminary steps
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
Ê "Removing the system air duct" on page 63
8.3.3.2 Removing the defectice rear fan
Ê Remove the rear fan as described in section "Removing the rear fan" on
page 193.
8.3.3.3 Installing the new rear fan
Ê Install the rear fan as described in section "Installing the rear fan" on
page 189.
8.3.3.4 Concluding steps
Ê "Installing the system air duct" on page 64
Ê "Reassembling" on page 64
Ê "Connecting the server to the mains" on page 74
Ê "Switching on the server" on page 75
Ê "Performing a fan test after replacing a defective fan" on page 106
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: tool-less
