244 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
10.1 Basic information
Figure 167: Memory overview
– The system board is equipped:
– D3079 (TX150 S8): 6 memory slots
– D3099 (TX200 S7): 12 memory slots (6 memory slots per CPU)
– The system has to be equipped with at least one memory module per CPU.
– Supported capacities: 2 GB, 4 GB, 8 GB, or 16 GB
– Maximum amount of RAM:
– D3079 (TX150 S8): 96 GB
– D3099 (TX200 S7): 192 GB
– Supported memory modules:
DDR3-1066 PC3-8500, DDR3-1333 PC3-10600 and DDR3-1600 PC3-
12800
Type Ranking
Error
Correction
SR: Single-Rank, DR: Dual-Rank SR DR
RDIMMs (Registered DIMMs) o o
ECC or non-
ECC
UDIMMs (Unbuffered DIMMs) o o
