340 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
Front panel and external connectors
13.2 Front LAN connector
13.2.1 Installing the front LAN connector
13.2.1.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 79
Ê "Locating the defective server" on page 47
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
Ê "Removing the system fan holder" on page 76
13.2.1.2 Installing the front LAN connector
Ê Disconnect the front panel cables from the system board as described in
section "Disconnecting cables" on page 329.
Ê Remove the front panel module from the chassis as described in section
"Removing the front panel module" on page 331.
Ê Remove the front panel module cover from the front panel frame as
described in section "Removing the front panel module cover" on page 334.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Slot screw driver
To Next Page
