314 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
Accessible drives and LSD
12.6.2.4 Concluding steps
Ê "Installing an HDD extension box" on page 172
Ê "Installing the system fan holder" on page 77
Ê "Reassembling" on page 64
Ê "Connecting the server to the mains" on page 74
Ê "Switching on the server" on page 75
12.6.3 Replacing the slimline ODD or LSD
12.6.3.1 Preliminary steps
Ê "Locating the defective server" on page 47
Ê "Removing backup and optical disk media" on page 82
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
I Removing the front cover is not required in order to replace the
slimline ODD or LSD module in the 2x 3.5-inch HDD extension box.
Ê "Removing the system fan holder" on page 76
Ê "Removing the HDD extension box" on page 179
12.6.3.2 Removing the defective slimline ODD
Ê Remove the slimline ODD from the 2x 3.5-inch HDD extension box as
described in section "Removing the slimline ODD" on page 310.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Slotted screw driver (for bending in or out accessible drive mounting
brackets)
